Multiple display
HDMI+VGA, Supports dual display and gives you an extraordinary visual experience.
Wide Application
This product provides you with great experiences
and helps you effeiciently achieve your goals.
Office
Medical
Transportation
Industry
Comprehensive I/O ports
This mini embedded motherboard also has rich I/O interfaces, which meets the requirement of the market.
产品概述

Powered by 2.41GHz dual core Celeron® processor J1800, this embedded board is power efficient (rated at a TDP of 10 watts) and adequate power-sensitive applications. It carries one DDR3L SO-DIMM slot with a total maximum capacity of 8GB to add higher bandwidth and lower latencies for processes.

This embedded board features 1080p HD display via VGA interface. It has 5_USB2.0 (4 headers), 1_USB3.0, 2_LAN, 1_PS/2, 1_LPT, 6_COM, 1_Mic in and 1_Audio out, which meets most requirements in the market.

This board can deliver cutting-edge performance with very low power consumption. With Celeron® processor you’ll enjoy stunning visuals, effortless multi-tasking, increased speed and enhanced security to help you create, play, entertain and achieve. Another special feature of this board is its 6_COM interfaces, which makes it ideal for applications like transportation, communication and so on.


产品特色
    • Intel Bay Trail-D Celeron processor, fanless design

    • Single channel DDR3L up to 8GB

    • Intel HD Graphics, display interfaces: VGA, HDMI, LVDS

    • 10/100/1000Mbit ethernet card

    • Sata2.0, mSata, Mini-PCIe, eMMC (optional)

    • 12V DC input
